Tời quay tay Fuji PRW-500N / PRW-500N Fuji Hand Winch

Tời quay tay Fuji PRW-500N / PRW-500N Fuji Hand Winch

Thời gian giao hàng: Vui lòng liên hệ 0988.324.548 / 0906.040.453
Tình trạng: Hàng mới 100%
Giá: Liên hệ
Hiệu lực giá bán:
  • Model: PRW-500N
  • Tải trọng: 500Kgs
  • Tang cuốn có thể chứa cáp 6mm x 40 mét cáp
  • Tỉ số truyền: 1/4.33
  • Trọng lượng ( thân + tay cầm ): 13.5Kg
  • Nhà sản xuất: Fuji MfG Co., Ltd

Tags:

PRW-N Series Fuji Hand Winch

  • Ratchet Handle both〈Moving Back and Forth+Rotating Handle〉Mechanical Brake is same as PNW series.
  • In the PRW series, the handle is designed in the ratchet style. Therefore, winding and rewinding cable is possible by repeatedly moving the handle from side to side. Even in narrow spaces where it is impossible to rotate handle 360 degree, the work can be done with the winches fixed directly to walls or floors. As with the SSW, PNW, PSW, PZW series, rotating handle operation is also possible.

    • PRW-N Series Fuji Hand Winch

    Model PRW-500N
    Load Rating 500kgf 1st layer
    Drum Capacity φ6mmＸ40.0m
    Gear Ratio 4.33 : 1
    Weight (Main unit + Handle) 13.5 kg

    PRW-N Series Fuji Hand Winch Instruction Manual
